Milling machine CORREANAYAK AXIA DUPLEX

Technical features

Dimensions

• Table surface mm: 3.500-25.000 x 2.000, 2.500, 3.000 x 300
• Max. load table kg/m2: 10.000 - 15.000

Traverses of axis

• Longitudinal mm: 4.000 - 25.000
• Cross mm: 1.250, 1.500
• Vertical mm: 3.000, 4.000

Milling head

• Spindle nose: ISO-50 / HSK 100
• Maximum power kw: 30
• Maximum torque Nm: 1.045

Feedrates

• Maximum feeds X, Y, Z m/mm: 30/40

Accesories

STANDARD EQUIPMENT

• Heidenhain CNC system
• UAD Universal Auto-Indexing Head, 0,1º Resolution
• Chips removal equipment
• A/C Electrical Cabinet
• Linear roller slideways on the X, Y, Z axes
• Lighting of the working area
• Ram droop & vertical axis dynamic compensation
• Hydraulic pack unit and oil chiller
• Linear feedback system on all three axes
• Coolant through the spindle (high pressure)



OPTIONS

• Other CNC’s
• Universal Auto-Indexing Differential Head 0,02º (UAD)
• Measurement and tool presetting touch probes
• 40 or 60 post automatic tool changer
• 8-post automatic tool changer
• Oil or air cleaning gun
• Centrifugal coolant filter
• Stationary floor plates
• Rotary tables
