The best second hand Milling Machines with performance of a new one.

Use our filters and select the best brands: Correa or Anayak.

Also select your business sector and contact us by our web form which you could find at the bottom of this page if you still cannot find the Milling Machine searched.

You have filtered by:

Bridge type CORREA FP50/80 milling machine- CORREA Service Bridge type CORREA FP50/80 milling machine- CORREA Service Bridge type CORREA FP50/80 milling machine- CORREA Service Bridge type CORREA FP50/80 milling machine- CORREA Service Bridge type CORREA FP50/80 milling machine- CORREA Service

CORREA FP50/80 - 892214

  • REFURBISHMENT ONGOING

CNC CORREA FP50/80 milling machine fully retrofitted by CORREA Service



Control unit HEIDENHAIN TNC-i540
Travels (X/Y/Z): 8000 / 3800 / 1500 mm.
Vertical capacity (VC): 168 / 1668 mm
Distance between columns: 3100 mm.
Universal Auto-indexing differential head (UAD) with 6000 rpm, turning every 0,02º.
Automatic 60-tool changer.
New electronic handwheel HR-510.
2 longitudinal hinge type chip conveyors.
External and high pressure through spindle coolant.
Guarding with 2 sliding doors and a perimetral wire-mesh fence.



Retrofitting of milling machines with excellent machining and accuracy


Find out more details!

CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199 CNC Milling machine CORREA FP40/40 – 895199

CORREA FP40/40 - 895199

  • IN STOCK

Second hand CNC CORREA milling machine fully refurbished.



Control unit HEIDENHAIN TNC-530.
Travels (X/Y/Z): 4000 / 3000 / 1000 mm.
Distance between columns: 2530 mm.
Universal manual milling head (UM40) with 5.000 r.p.m. in direct spindle.
Electronic handwheel HR-420.
External coolant.
Guarding.

Retrofitting of milling machine with excellent machining and accuracy.

Find out more details about this second hand bridge milling machine!

CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE CORREA FP40/60 milling machine retrofitting by CORREA SERVICE

CORREA FP40/60 - 8950202

  • REFURBISHMENT ONGOING

CNC CORREA FP40/60 milling machine fully refurbished



New control unit HEIDENHAIN TNC-320.
Travels (X/Y/Z): 6000 / 3800 / 1000 mm.
Vertical capacity (VC): 500 / 1500 mm.
Distance between columns: 3100 mm.
Universal head (UM40 – Body B: manual / Body C: 3º auto-indexing) and direct spindle. With 6000 rpm.
New electronic handwheel HR-510.
2 longitudinal pallets chip conveyors.
External coolant. Internal high pressure through spindle coolant only in direct exit head.
Guarding with 2 sliding doors and a new perimetral wire-mesh safety fence.


Retrofitting of milling machines with excellent machining and accuracy


Find out more details!

CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service CORREA FP40/50 milling machine - Retrofitted by NC Service

CORREA FP40/50

  • REFURBISHMENT ONGOING

Second hand CORREA bridge type milling machine



Control Unit: SIEMENS 840D
Travels (X/Y/Z): 5000 / 3250 / 1000 mm
Distance between columns: 2500 mm
C5E-2 axis continuous milling head
Automatic tool changer of 60 tools (ATC60)
NEW! Electronic handwheel
Guarding

Find out more about this used bridge milling machine here!

CORREA FP50/50 milling machine - NC Service CORREA FP50/50 milling machine - NC Service CORREA FP50/50 milling machine - NC Service CORREA FP50/50 milling machine - NC Service CORREA FP50/50 milling machine - NC Service

CORREA FP50/50 - 892177

  • REFURBISHMENT ONGOING

CNC CORREA milling machine fully refurbished


New control unit HEIDENHAIN TNC-i640.
Travels (X/Y/Z): 5000 / 3250 / 1000 mm.
Vertical capacity (VC): 450 / 1450 mm
Distance between columns: 2435 mm.
Universal Auto-indexing differential head (UAD) with 6000 rpm.
New electronic handwheel HR-510.
Transversal hinge type chip conveyor.
Option of installing a new automatic tool changer.
External and high pressure through spindle coolant.
Guarding with 2 sliding doors and a perimetral wire-mesh fence.



Retrofitting of milling machines with excellent machining and accuracy


Find out more details!

CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service CORREA milling machine with new HEIDENHAIN - CORREA Service

CORREA FP40/40 - 895234

  • REFURBISHMENT ONGOING

CORREA milling machine fully retrofitted with new HEIDENHAIN TNC-i640



Control unit: NEW HEIDENHAIN TNC-i640.
Travels (X/Y/Z): 4000 / 3000 / 1000 mm.
Distance between columns: 2500 mm.
Vertical capacity (VC): 240 / 1240 mm.
Universal Auto-indexing differential head (UAD) with 6000 rpm.
Automatic tool changer: ATC-60 (sale option with no ATC).
Transversal chip conveyor.
Electronic handwheel: HR-420.
External and high pressure through spindle coolant.
Guarding with new safety perimetral fence installation.



Retrofitting of CORREA milling machines with excellent machining and accuracy


Find out more details!

Bridge type milling machine CORREA FP30/30 - 8900205 Bridge type milling machine CORREA FP30/30 - 8900205 Bridge type milling machine CORREA FP30/30 - 8900205 Bridge type milling machine CORREA FP30/30 - 8900205 Bridge type milling machine CORREA FP30/30 - 8900205 Bridge type milling machine CORREA FP30/30 - 8900205

CORREA FP30/30 - 8900205

  • REFURBISHMENT ONGOING

Used CORREA bridge type milling machine.

Control unit HEIDENHAIN TNC-426.
Travels (X/Y/Z): 2500 / 1800 / 800 mm.
Distance between columns: 1680 mm.
Standard vertical spindle.
Heidenhain electronic handwheel.
Guarding.

Used bridge millling machine for sale here!

Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine Gantry type CORREA PANTERA milling machine

CORREA PANTERA

  • REFURBISHMENT ONGOING

Retrofitted CORREA gantry milling machine.

Control unit SIEMENS 840D.
Travels (X/Y/Z): 14000 / 3100 / 1200 mm.
Distance between columns: 4417 mm.
5 Axes "C5C" Electrospindle 18.000 r.p.m.
Automatic tool changer of 24 tools (ATC24)
Internal & external coolant.
Guarding.

Clearance sale!

Used milling machine for sale here!

Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service Used NICOLAS CORREA milling machines - NC Service

CORREA FP40/40 - 895235

  • REFURBISHMENT ONGOING

Second hand CNC CORREA milling machine fully refurbished


Control unit HEIDENHAIN TNC-i530.
Travels (X/Y/Z): 4000 / 3000 / 1000 mm.
Distance between columns: 2435 mm.
Universal Auto-indexing differential head (UAD) with 6000 rpm.
Automatic tool changer (ATC30).
Electronic handwheel HR-420.
External and high pressure through spindle coolant.
Guarding.

Retrofitting of milling machines with excellent machining and accuracy


Find out more details!


Pictures at previous customer, before retrofitting process.

Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304 Bridge type milling machine CORREA FP40/40 - 8950304

CORREA FP40/40 - 8950304

  • SOLD

Second hand CORREA bridge type milling machine



Control unit HEIDENHAIN TNC-426.
Travels (X/Y/Z): 3500 / 2500 / 1000 mm.
Distance between columns: 2040 mm.
Standard vertical spindle, direct exit.
Transversal metal hinged conveyor.
Guarding.
Option: Workpiece measurement probe: Heidenhain TS-642.

Retrofitting CORREA used bridge milling machine for sale here!

View all results

Can't you find the milling machine you want?

Please complete the following form and we'll help you look.
